دیتاشیت LM2903N/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LM2903
|
| حجم فایل |
1902.558
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
21
|
مشخصات
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
Texas Instruments LM2903N/NOPB
-
Output Type:
互补
-
Supply Voltage:
2V~36V;1V~18V
-
Number of Elements:
-
-
Operating Temperature:
-40°C~+85°C
-
Input Bias Current (Ib):
0.25uA
-
Input Offset Voltage (Vos):
7mV
-
Input Hysteresis Voltage (Vhys):
-
-
Common Mode Rejection Ratio (CMRR):
80dB
-
Package:
PDIP-8
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Type:
General Purpose
-
Voltage - Supply, Single/Dual (±):
2V ~ 36V, ±1V ~ 18V
-
Voltage - Input Offset (Max):
7mV @ 5V
-
Current - Input Bias (Max):
0.25µA @ 5V
-
Current - Output (Typ):
16mA @ 5V
-
Current - Quiescent (Max):
2.5mA
-
CMRR, PSRR (Typ):
-
-
Propagation Delay (Max):
-
-
Hysteresis:
-
-
Package / Case:
8-DIP (0.300", 7.62mm)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
8-DIP
-
Base Part Number:
LM2903
-
detail:
Comparator General Purpose CMOS, DTL, ECL, MOS, Open-Collector, TTL 8-DIP
