LM741CN/NOPB دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LM741CN/NOPB
|
|
حجم فایل
|
49.722
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Operational Amplifier
-
Datasheet:
Texas Instruments LM741CN/NOPB
-
-3db Bandwidth:
-
-
Output Current:
25mA
-
Supply Current:
1.5mA
-
Number of Circuits:
1
-
Operating Temperature:
0°C~+70°C
-
Current - Input Bias(Ib):
80nA
-
Gain Bandwidth Product(GBP):
1.5MHz
-
Package:
DIP-8
-
Manufacturer:
Texas Instruments
-
Gain Bandwidth Product:
1.5MHz
-
Current - Input Bias:
80nA
-
Base Part Number:
LM741
-
Package / Case:
8-DIP (0.300", 7.62mm)
-
Current - Supply:
1.7mA
-
Supplier Device Package:
8-PDIP
-
Part Status:
Obsolete
-
Amplifier Type:
General Purpose
-
Series:
-
-
Slew Rate:
0.5V/µs
-
Current - Output / Channel:
25mA
-
Voltage - Supply, Single/Dual (±):
10V ~ 36V, ±5V ~ 18V
-
Voltage - Input Offset:
2mV
-
Packaging:
Tube
-
Mounting Type:
Through Hole
-
Output Type:
-
-
detail:
General Purpose Amplifier 1 Circuit 8-PDIP
