TPS62095RGTR 数据手册
其他文档
TPS62095 28 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS62095RGTR
- Output Type: Adjustable
- Input Voltage: 2.5V~5.5V
- Output Voltage: 0.8V~5.5V
- Number of Outputs: 1
- Switching Frequency: 1.4MHz
- Output Current (Max): 4A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: QFN-16-EP(3x3)
- Manufacturer: Texas Instruments
- Frequency - Switching: 1.4MHz
- Package / Case: 16-VFQFN Exposed Pad
- Supplier Device Package: 16-QFN (3x3)
- Voltage - Output (Min/Fixed): 0.8V
- Current - Output: 4A
- Output Configuration: Positive
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Voltage - Output (Max): 5.5V
- Series: DCS-Control™
- Mounting Type: Surface Mount
- Voltage - Input (Max): 5.5V
- Base Part Number: TPS620
- Voltage - Input (Min): 2.5V
- Synchronous Rectifier: Yes
- detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 4A 16-VFQFN Exposed Pad
