دیتاشیت TMUX1119DCKR
مشخصات دیتاشیت
| نام دیتاشیت |
TMUX1119
|
| حجم فایل |
1565.382
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
37
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TMUX1119DCKR
-
Supply Voltage:
1.08V~5.5V
-
Switch Circuit:
SPDT(SPDT)
-
Number of Channels:
1
-
On-State Resistance (Max):
4Ω
-
Package:
SC-70-6
-
Manufacturer:
Texas Instruments
-
Channel Capacitance (CS(off), CD(off)):
6pF
-
Package / Case:
6-TSSOP, SC-88, SOT-363
-
Channel-to-Channel Matching (ΔRon):
130mOhm
-
Current - Leakage (IS(off)) (Max):
80pA
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Crosstalk:
-45dB @ 10MHz
-
Packaging:
Cut Tape (CT)
-
Supplier Device Package:
SC-70-6
-
Part Status:
Active
-
Base Part Number:
TMUX11
-
Voltage - Supply, Single (V+):
1.08V ~ 5.5V
-
Multiplexer/Demultiplexer Circuit:
2:1
-
Voltage - Supply, Dual (V±):
-
-
Charge Injection:
-6pC
-
-3db Bandwidth:
250MHz
-
Switch Time (Ton, Toff) (Max):
-
-
Series:
-
-
Mounting Type:
Surface Mount
-
Number of Circuits:
1
-
detail:
1 Circuit IC Switch 2:1 4Ohm SC-70-6
