دیتاشیت TLV2452CDGKR
مشخصات دیتاشیت
| نام دیتاشیت | TLV2450-55, TLV245xA |
|---|---|
| حجم فایل | 2644.096 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 63 |
دانلود دیتاشیت TLV2450-55, TLV245xA |
TLV2450-55, TLV245xA Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Texas Instruments TLV2452CDGKR
- Rail to Rail: 轨到轨
- -3db Bandwidth: -
- Output Current: 10mA
- Operating Temperature: 0°C~+70°C
- Current - Input Bias(Ib): 500pA
- Gain Bandwidth Product(GBP): 220kHz
- Package: VSSOP-8
- Manufacturer: Texas Instruments
- Base Part Number: TLV245
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Gain Bandwidth Product: 220kHz
- Series: -
- Slew Rate: 0.11V/µs
- Current - Supply: 23µA
- Voltage - Supply, Single/Dual (±): 2.7V ~ 6V, ±1.35V ~ 3V
- Current - Input Bias: 500pA
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Part Status: Active
- Voltage - Input Offset: 300µV
- Amplifier Type: General Purpose
- Number of Circuits: 2
- Output Type: Rail-to-Rail
- Current - Output / Channel: 10mA
- Supplier Device Package: 8-VSSOP
- detail: General Purpose Amplifier 2 Circuit Rail-to-Rail 8-VSSOP
