دیتاشیت TPS63000IDRCRQ1
مشخصات دیتاشیت
| نام دیتاشیت |
TPS63000-Q1
|
| حجم فایل |
1803.888
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
21
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Datasheet:
Texas Instruments TPS63000IDRCRQ1
-
Package:
DFN-10(3x3)
-
Manufacturer:
Texas Instruments
-
Topology:
Buck-Boost
-
Frequency - Switching:
1.25MHz ~ 1.5MHz
-
Number of Outputs:
1
-
Package / Case:
10-VFDFN Exposed Pad
-
Supplier Device Package:
10-VSON (3x3)
-
Voltage - Output (Min/Fixed):
1.2V
-
Current - Output:
1.6A (Switch)
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Output Configuration:
Positive
-
Packaging:
Digi-Reel®
-
Function:
Step-Up/Step-Down
-
Part Status:
Active
-
Voltage - Output (Max):
5.5V
-
Series:
Automotive, AEC-Q100
-
Mounting Type:
Surface Mount
-
Voltage - Input (Max):
5.5V
-
Output Type:
Adjustable
-
Base Part Number:
TPS630
-
Voltage - Input (Min):
1.8V
-
Synchronous Rectifier:
Yes
-
detail:
Buck-Boost Switching Regulator IC Positive Adjustable 1.2V 1 Output 1.6A (Switch) 10-VFDFN Exposed Pad
