OPA743,2743,4743 Datasheet Datasheet

OPA743,2743,4743 Datasheet

Datasheet specifications

Datasheet's name OPA743,2743,4743 Datasheet
File size 883.612 KB
File type pdf
Number of pages 16

Download Datasheet OPA743,2743,4743 Datasheet

Download Datasheet

Other documentations

OPA4743UA 17 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments OPA743NA/3K
  • Rail to Rail: 轨到轨
  • -3db Bandwidth: -
  • Output Current: 20mA
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 1pA
  • Gain Bandwidth Product(GBP): 7MHz
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Base Part Number: OPA743
  • Package / Case: SC-74A, SOT-753
  • Gain Bandwidth Product: 7MHz
  • Series: -
  • Slew Rate: 10V/µs
  • Current - Supply: 1.1mA
  • Voltage - Supply, Single/Dual (±): 3.5V ~ 12V, ±1.75V ~ 6V
  • Current - Input Bias: 1pA
  • Packaging: Cut Tape (CT)
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Voltage - Input Offset: 1.5mV
  • Amplifier Type: General Purpose
  • Output Type: Rail-to-Rail
  • Current - Output / Channel: 20mA
  • Supplier Device Package: SOT-23-5
  • detail: General Purpose Amplifier 1 Circuit Rail-to-Rail SOT-23-5
