UCC27211DRMT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
UCC27211DRMT
|
|
حجم فایل
|
101.638
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
39
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Gate Drive ICs
-
Datasheet:
Texas Instruments UCC27211DRMT
-
Fall Time:
5.5ns
-
Load Type:
MOSFET
-
Rise Time:
7.2ns
-
Supply Voltage:
8V~17V
-
Number of Drivers:
2
-
Driven Configuration:
Half Bridge
-
Operating Temperature:
-40°C~+140°C@(Tj)
-
Peak Output Current(sink):
4A
-
Peak Output Current(source):
4A
-
Package:
VSON-8(4x4)
-
Manufacturer:
Texas Instruments
-
Input Type:
Non-Inverting
-
Base Part Number:
UCC272
-
Current - Peak Output (Source, Sink):
4A, 4A
-
Package / Case:
8-VDFN Exposed Pad
-
Rise / Fall Time (Typ):
7.2ns, 5.5ns
-
High Side Voltage - Max (Bootstrap):
120V
-
Supplier Device Package:
8-VSON (4x4)
-
Logic Voltage - VIL, VIH:
1.3V, 2.7V
-
Packaging:
Cut Tape (CT)
-
Channel Type:
Independent
-
Voltage - Supply:
8V ~ 17V
-
Part Status:
Active
-
Series:
-
-
Gate Type:
N-Channel MOSFET
-
Mounting Type:
Surface Mount
-
detail:
Half-Bridge Gate Driver IC Non-Inverting 8-VSON (4x4)
