دیتاشیت TPS4H000BQPWPRQ1
مشخصات دیتاشیت
| نام دیتاشیت | TPS4H000-Q1 Datasheet |
|---|---|
| حجم فایل | 1555.424 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 39 |
دانلود دیتاشیت TPS4H000-Q1 Datasheet |
TPS4H000-Q1 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Power Distribution Switches
- Datasheet: Texas Instruments TPS4H000BQPWPRQ1
- Package: TSSOP-20-EP
- Manufacturer: Texas Instruments
- Switch Type: General Purpose
- Number of Outputs: 4
- Package / Case: 20-PowerTSSOP (0.173", 4.40mm Width)
- Current - Output (Max): 750mA
- Operating Temperature: -40°C ~ 125°C (TA)
- Output Configuration: High Side
- Ratio - Input:Output: 1:1
- Supplier Device Package: 20-HTSSOP
- Part Status: Active
- Base Part Number: TPS4H0
- Output Type: N-Channel
- Rds On (Typ): 1Ohm
- Input Type: -
- Voltage - Supply (Vcc/Vdd): Not Required
- Interface: On/Off
- Features: Status Flag
- Fault Protection: Current Limiting (Adjustable), Over Temperature
- Voltage - Load: 3.4V ~ 40V
- Packaging: Tape & Reel (TR)
- Series: Automotive, AEC-Q100
- Mounting Type: Surface Mount
- detail: Power Switch/Driver 1:1 N-Channel 750mA 20-HTSSOP
