- دیتاشیت TPS7A4901DRBR
TPS7A4901DRBR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPS7A4901DRBR |
|---|---|
| حجم فایل | 105.829 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 39 |
دانلود دیتاشیت TPS7A4901DRBR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS7A49 Datasheet 39 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS7A4901DRBR
- Output Type: Adjustable
- Output Current: 150mA
- Output Voltage: 1.194V~33V
- Dropout Voltage: 0.6V@(150mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 100uA
- Power Supply Rejection Ratio (PSRR): 72dB@(120Hz)
- Package: SON-8-EP(3x3)
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 0.6V @ 150mA
- Package / Case: 8-VDFN Exposed Pad
- Control Features: Enable
- Current - Output: 150mA
- Output Configuration: Positive
- Voltage - Output (Min/Fixed): 1.194V
- Supplier Device Package: 8-SON (3x3)
- Part Status: Active
- Current - Supply (Max): 800µA
- Base Part Number: TPS7A4
- PSRR: 72dB (120Hz)
- Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- Packaging: Cut Tape (CT)
- Voltage - Output (Max): 33V
- Voltage - Input (Max): 35V
- Series: -
- Mounting Type: Surface Mount
- Current - Quiescent (Iq): 100µA
- Number of Regulators: 1
- detail: Linear Voltage Regulator IC 1 Output 150mA 8-SON (3x3)
