LM6511 دیتاشیت

LM6511

مشخصات دیتاشیت

نام دیتاشیت LM6511
حجم فایل 1017.362 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

مشاهده دیتاشیت LM6511

دانلود دیتاشیت

سایر مستندات

LM6511IMX/NOPB 13 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments LM6511IMX/NOPB
  • Output Type: 开集
  • Supply Current: 3.5mA
  • Supply Voltage: 2.5V~30V
  • Number of Elements: 1
  • Operating Temperature: -40°C~+85°C
  • Input Bias Current (Ib): 0.13uA
  • Input Offset Voltage (Vos): 5mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): -
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • CMRR, PSRR (Typ): 72dB CMRR
  • Voltage - Supply, Single/Dual (±): 2.5V ~ 30V
  • Base Part Number: LM6511
  • Packaging: Cut Tape (CT)
  • Type: General Purpose
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Current - Input Bias (Max): 0.13µA @ 2.7V
  • Supplier Device Package: 8-SOIC
  • Mounting Type: Surface Mount
  • Part Status: Obsolete
  • Current - Quiescent (Max): 3.5mA
  • Series: -
  • Hysteresis: -
  • Voltage - Input Offset (Max): 5mV @ 2.7V
  • Current - Output (Typ): -
  • Propagation Delay (Max): -
  • detail: Comparator General Purpose CMOS, Open-Collector, TTL 8-SOIC
