دیتاشیت LM5009MM/NOPB

LM5009

مشخصات دیتاشیت

نام دیتاشیت LM5009
حجم فایل 1098.155 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت LM5009

LM5009 Datasheet

مشخصات

  • Topology: Buck
  • Frequency - Switching: -
  • Number of Outputs: 1
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 8-VSSOP
  • Voltage - Output (Min/Fixed): 2.5V
  • Current - Output: 150mA
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Output Configuration: Positive
  • Packaging: Cut Tape (CT)
  • Function: Step-Down
  • Part Status: Not For New Designs
  • Manufacturer: Texas Instruments
  • Voltage - Output (Max): 85V
  • Series: -
  • Mounting Type: Surface Mount
  • Voltage - Input (Max): 95V
  • Output Type: Adjustable
  • Base Part Number: LM5009
  • Voltage - Input (Min): 9.5V
  • Synchronous Rectifier: No
  • detail: Buck Switching Regulator IC Positive Adjustable 2.5V 1 Output 150mA 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
