دیتاشیت TPS54140DGQR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS54140
|
| حجم فایل |
2228.594
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
52
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Texas Instruments TPS54140DGQR
-
Output Type:
Adjustable
-
Input Voltage:
3.5V~42V
-
Output Voltage:
0.8V~39V
-
Number of Outputs:
1
-
Switching Frequency:
2.5MHz
-
Output Current (Max):
1.5A
-
Operating Temperature:
-40°C~+150°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
MSOP-10-EP
-
Manufacturer:
Texas Instruments
-
Frequency - Switching:
100kHz ~ 2.5MHz
-
Package / Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
-
Supplier Device Package:
10-MSOP-PowerPad
-
Voltage - Output (Min/Fixed):
0.8V
-
Current - Output:
1.5A
-
Output Configuration:
Positive
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Output (Max):
39V
-
Series:
Eco-Mode™
-
Mounting Type:
Surface Mount
-
Voltage - Input (Max):
42V
-
Base Part Number:
TPS541
-
Voltage - Input (Min):
3.5V
-
Synchronous Rectifier:
No
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 1.5A 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
