دیتاشیت LP2989IMX-3.3/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LP2989 Datasheet |
|---|---|
| حجم فایل | 1950.633 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت LP2989 Datasheet |
LP2989 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Feature: Overcurrent Protection;Thermal Protection
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP2989IMX-3.3/NOPB
- Output Type: Fixed
- Output Current: 500mA
- Output Voltage: 3.3V
- Dropout Voltage: 650mV@(500mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 16V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 175uA
- Power Supply Rejection Ratio (PSRR): 60dB@(1kHz)
- Package: SOP-8
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 0.65V @ 500mA
- Current - Supply (Max): 9mA
- Current - Output: 500mA
- Current - Quiescent (Iq): 175µA
- Voltage - Input (Max): 16V
- Base Part Number: LP2989
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Voltage - Output (Max): -
- Output Configuration: Positive
- Series: -
- Supplier Device Package: 8-SOIC
- PSRR: 60dB (1kHz)
- Part Status: Obsolete
- Mounting Type: Surface Mount
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Output (Min/Fixed): 3.3V
- Number of Regulators: 1
- Packaging: Tape & Reel (TR)
- detail: Linear Voltage Regulator IC 1 Output 500mA 8-SOIC
