MUX508IPWR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MUX508IPWR |
|---|---|
| حجم فایل | 87.42 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 41 |
دانلود دیتاشیت MUX508IPWR |
دانلود دیتاشیت |
|---|
سایر مستندات
MUX508, MUX509 Datasheet 42 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Texas Instruments MUX508IPWR
- Turn-on time: 136ns
- Turn-off time: 75ns
- Supply Voltage: 10V~36V
- Switch Circuit: -
- Number of Channels: 1
- On-State Resistance (Max): 170Ω
- Package: TSSOP-16
- Manufacturer: Texas Instruments
- Channel Capacitance (CS(off), CD(off)): 2.4pF, 7.5pF
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Channel-to-Channel Matching (ΔRon): 2.4Ohm
- Current - Leakage (IS(off)) (Max): 1nA
- Operating Temperature: -40°C ~ 125°C (TA)
- Crosstalk: -96dB @ 1MHz
- Packaging: Cut Tape (CT)
- Supplier Device Package: 16-TSSOP
- Part Status: Active
- Base Part Number: MUX508
- Voltage - Supply, Single (V+): 10V ~ 36V
- Multiplexer/Demultiplexer Circuit: 8:1
- Voltage - Supply, Dual (V±): ±5V ~ 18V
- Charge Injection: 0.3pC
- -3db Bandwidth: -
- Switch Time (Ton, Toff) (Max): 136ns, 75ns
- Series: -
- Mounting Type: Surface Mount
- Number of Circuits: 1
- detail: 1 Circuit IC Switch 8:1 170Ohm 16-TSSOP
