دیتاشیت LM7805CT/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM340(A), LM78xx Datasheet |
|---|---|
| حجم فایل | 3846.762 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت LM340(A), LM78xx Datasheet |
LM340(A), LM78xx Datasheet Datasheet |
|---|
مشخصات
- Voltage - Output (Min/Fixed): 5V
- Voltage Dropout (Max): 2V @ 1A
- Package / Case: TO-220-3
- Control Features: -
- Supplier Device Package: TO-220-3
- Current - Output: 1A
- Operating Temperature: 0°C ~ 125°C
- Voltage - Output (Max): -
- Packaging: Tube
- Mounting Type: Through Hole
- Part Status: Active
- Manufacturer: Texas Instruments
- Output Configuration: Positive
- Series: -
- Base Part Number: LM7805
- Voltage - Input (Max): 35V
- Output Type: Fixed
- Protection Features: Over Current, Over Temperature, Short Circuit
- PSRR: 80dB (120Hz)
- Number of Regulators: 1
- Current - Quiescent (Iq): 6mA
- detail: Linear Voltage Regulator IC 1 Output 1A TO-220-3
