ISO721DR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ISO721DR
|
|
حجم فایل
|
131.339
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
39
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Digital Isolators
-
Data Rate:
100Mbps
-
Datasheet:
Texas Instruments ISO721DR
-
Applications:
General-purpose
-
Supply Voltage:
3V~5.5V
-
Forward Channel:
1
-
Reverse channel:
0
-
Number of Channels:
1
-
Isolation Technology:
电容隔离
-
Operating Temperature:
-40°C~+125°C
-
Voltage Isolation or Not:
带电压隔离
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Inputs - Side 1/Side 2:
1/0
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Rise / Fall Time (Typ):
1ns, 1ns
-
Type:
General Purpose
-
Packaging:
Cut Tape (CT)
-
Supplier Device Package:
8-SOIC
-
Part Status:
Active
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Base Part Number:
ISO721
-
Pulse Width Distortion (Max):
2ns
-
Isolated Power:
No
-
Channel Type:
Unidirectional
-
Voltage - Supply:
3V ~ 5.5V
-
Series:
-
-
Propagation Delay tpLH / tpHL (Max):
24ns, 24ns
-
Mounting Type:
Surface Mount
-
Voltage - Isolation:
2500Vrms
-
Technology:
Capacitive Coupling
-
detail:
General Purpose Digital Isolator 2500Vrms 1 Channel 100Mbps 25kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
