دیتاشیت LM7905CT/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LM7905,12,15
|
| حجم فایل |
1228.972
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments LM7905CT/NOPB
-
Output Current:
1.5A
-
Output Voltage:
5V
-
Dropout Voltage:
1.1V@(1A)
-
Output Polarity:
Negative
-
Number of Outputs:
1
-
Maximum Input Voltage:
25V
-
Operating Temperature:
0°C~+125°C
-
Quiescent Current (Ground Current):
1mA
-
Power Supply Rejection Ratio (PSRR):
66dB@(120Hz)
-
Package:
TO-220
-
Manufacturer:
Texas Instruments
-
Voltage - Input (Max):
-25V
-
Current - Quiescent (Iq):
1mA
-
Output Configuration:
Negative
-
Base Part Number:
LM7905
-
Voltage - Output (Min/Fixed):
-5V
-
Protection Features:
Over Temperature, Short Circuit
-
Series:
-
-
Packaging:
Tube
-
PSRR:
66dB (120Hz)
-
Supplier Device Package:
TO-220-3
-
Package / Case:
TO-220-3
-
Number of Regulators:
1
-
Part Status:
Not For New Designs
-
Output Type:
Fixed
-
Control Features:
-
-
Voltage - Output (Max):
-
-
Mounting Type:
Through Hole
-
Voltage Dropout (Max):
1.1V @ 1A
-
Current - Output:
1.5A
-
detail:
Linear Voltage Regulator IC 1 Output 1.5A TO-220-3
