TPS78601DCQR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TPS78601DCQR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS78601DCQR
Output Type: Adjustable
Output Current: 1.5A
Output Voltage: 1.2V~5.5V
Dropout Voltage: 470mV@(1.5A)
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 5.5V
Operating Temperature: -40°C~+125°C
Quiescent Current (Ground Current): 385uA
Power Supply Rejection Ratio (PSRR): 59dB@(100Hz),32dB@(100kHz)
Package: SOT-223-6
Manufacturer: Texas Instruments
Voltage - Output (Min/Fixed): 1.2V
Voltage Dropout (Max): 0.47V @ 1.5A
Package / Case: SOT-223-6
Control Features: Enable
Supplier Device Package: SOT-223-6
Current - Output: 1.5A
Voltage - Output (Max): 5.5V
Packaging: Cut Tape (CT)
Mounting Type: Surface Mount
Part Status: Active
Output Configuration: Positive
Series: -
Base Part Number: TPS786
Voltage - Input (Max): 5.5V
Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
PSRR: 59dB ~ 32dB (100Hz ~ 100kHz)
Number of Regulators: 1
Current - Quiescent (Iq): 385µA
detail: Linear Voltage Regulator IC 1 Output 1.5A SOT-223-6
