دیتاشیت LM2937ES-10/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LM2937
|
| حجم فایل |
2100.988
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
30
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments LM2937ES-10/NOPB
-
Package:
TO-263-3
-
Manufacturer:
Texas Instruments
-
Control Features:
-
-
Base Part Number:
LM2937
-
Package / Case:
TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
-
Current - Supply (Max):
20mA
-
Part Status:
Obsolete
-
Current - Output:
500mA
-
PSRR:
-
-
Series:
-
-
Voltage - Output (Min/Fixed):
10V
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
2mA
-
Output Configuration:
Positive
-
Voltage Dropout (Max):
1V @ 50mA
-
Operating Temperature:
-40°C ~ 125°C
-
Supplier Device Package:
DDPAK/TO-263-3
-
Protection Features:
Over Temperature, Reverse Polarity, Short Circuit
-
Voltage - Input (Max):
26V
-
Output Type:
Fixed
-
Packaging:
Tube
-
Voltage - Output (Max):
-
-
detail:
Linear Voltage Regulator IC 1 Output 500mA DDPAK/TO-263-3
