دیتاشیت LM5018MRX/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM5018MRX/NOPB |
|---|---|
| حجم فایل | 95.503 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 35 |
LM5018MRX/NOPB |
دانلود دیتاشیت |
|---|
سایر مستندات
LM5018 Datasheet 35 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments LM5018MRX/NOPB
- Output Type: Adjustable
- Input Voltage: 7.5V~100V
- Output Voltage: 1.225V~90V
- Number of Outputs: 1
- Switching Frequency: 1MHz
- Output Current (Max): 300mA
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: SO-8-EP
- Manufacturer: Texas Instruments
- Frequency - Switching: Adj to 1MHz
- Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SO PowerPad
- Voltage - Output (Min/Fixed): 1.225V
- Current - Output: 300mA
- Output Configuration: Positive, Isolation Capable
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Max): 90V
- Series: -
- Mounting Type: Surface Mount
- Voltage - Input (Max): 100V
- Base Part Number: LM5018
- Voltage - Input (Min): 7.5V
- Synchronous Rectifier: Yes
- detail: Buck Switching Regulator IC Positive, Isolation Capable Adjustable 1.225V 1 Output 300mA 8-PowerSOIC (0.154", 3.90mm Width)
