LM338T/NOPB 数据手册
其他文档
LM138, 338 29 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM338T/NOPB
- Output Type: Adjustable
- Output Current: 5A
- Output Voltage: 1.24V~32V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 40V
- Operating Temperature: 0°C~+125°C
- Package: TO-220
- Manufacturer: Texas Instruments
- Voltage - Output (Min/Fixed): 1.24V
- Voltage Dropout (Max): -
- Package / Case: TO-220-3
- Control Features: -
- Supplier Device Package: TO-220-3
- Current - Output: 5A
- Voltage - Output (Max): 32V
- Packaging: Tube
- Mounting Type: Through Hole
- Part Status: Active
- Output Configuration: Positive
- Series: -
- Base Part Number: LM338
- Voltage - Input (Max): 40V
- PSRR: 75dB ~ 60dB (120Hz)
- Number of Regulators: 1
- Protection Features: Over Temperature, Short Circuit
- detail: Linear Voltage Regulator IC 1 Output 5A TO-220-3
