TPS7A7300RGWT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS7A7300RGWT
|
|
حجم فایل
|
76.061
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
42
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS7A7300RGWT
-
Package:
QFN-20-EP(5x5)
-
Manufacturer:
Texas Instruments
-
Voltage - Output (Min/Fixed):
0.9V
-
Voltage Dropout (Max):
0.7V @ 3A
-
Package / Case:
20-VQFN Exposed Pad
-
Control Features:
Enable, Power Good, Soft Start
-
Supplier Device Package:
20-VQFN (5x5)
-
Current - Output:
3A
-
Operating Temperature:
-40°C ~ 125°C
-
Voltage - Output (Max):
5V
-
Packaging:
Cut Tape (CT)
-
Mounting Type:
Surface Mount
-
Part Status:
Active
-
Output Configuration:
Positive
-
Series:
-
-
Base Part Number:
TPS7A7
-
Voltage - Input (Max):
6.5V
-
Output Type:
Adjustable (Fixed)
-
Protection Features:
Over Current, Over Temperature, Under Voltage Lockout (UVLO)
-
PSRR:
-
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
4mA
-
detail:
Linear Voltage Regulator IC 1 Output 3A 20-VQFN (5x5)
