دیتاشیت INA321EA/250

INA321, INA2321 Datasheet

مشخصات دیتاشیت

نام دیتاشیت INA321, INA2321 Datasheet
حجم فایل 1008.779 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت INA321, INA2321 Datasheet

INA321, INA2321 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Instrumentation OpAmps
  • Datasheet: Texas Instruments INA321EA/250
  • -3db Bandwidth: 500kHz
  • Number of Circuits: 1
  • Operating Temperature: -55°C~+125°C
  • Current - Input Bias(Ib): 0.5pA
  • Gain Bandwidth Product(GBP): -
  • Voltage - Input Offset(Vos): 200uV
  • Package: VSSOP-8
  • Manufacturer: Texas Instruments
  • Base Part Number: INA321
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Series: -
  • Supplier Device Package: 8-VSSOP
  • Slew Rate: 0.4V/µs
  • Current - Supply: 40µA
  • Voltage - Supply, Single/Dual (±): 2.5V ~ 5.5V, ±1.25V ~ 2.75V
  • Current - Input Bias: 0.5pA
  • Packaging: Digi-Reel®
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Voltage - Input Offset: 200µV
  • Amplifier Type: Instrumentation
  • Output Type: Rail-to-Rail
  • Current - Output / Channel: 16mA
  • detail: Instrumentation Amplifier 1 Circuit Rail-to-Rail 8-VSSOP
