دیتاشیت LM3940IT-3.3/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM3940 |
|---|---|
| حجم فایل | 2048.246 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت LM3940 |
LM3940 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM3940IT-3.3/NOPB
- Output Current: 1A
- Output Voltage: 3.3V
- Dropout Voltage: 0.2V@(100mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 7.5V
- Operating Temperature: -40°C~+125°C
- Package: TO-220
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 7.5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.2V @ 100mA
- Output Configuration: Positive
- Series: -
- Base Part Number: LM3940
- Supplier Device Package: TO-220-3
- Mounting Type: Through Hole
- Voltage - Output (Min/Fixed): 3.3V
- Number of Regulators: 1
- PSRR: -
- Output Type: Fixed
- Package / Case: TO-220-3
- Packaging: Tube
- Protection Features: Over Temperature, Short Circuit
- Control Features: -
- Part Status: Not For New Designs
- Current - Output: 1A
- detail: Linear Voltage Regulator IC 1 Output 1A TO-220-3
