دیتاشیت ADS7846E/2K5
مشخصات دیتاشیت
| نام دیتاشیت | ADS7846 Datasheet |
|---|---|
| حجم فایل | 1667.238 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 32 |
دانلود دیتاشیت ADS7846 Datasheet |
ADS7846 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Touch Screen Controllers
- Datasheet: Texas Instruments ADS7846E/2K5
- InterfaceType: SPI
- Operating Voltage: 2.2V~5.25V
- Resolution (Bits): 12
- Touch Screen Type: 4 Wire Resistive Type
- Operating Temperature: -40°C~+85°C
- Package: SSOP-16-150mil-0.635mm
- Manufacturer: Texas Instruments
- Base Part Number: ADS7846
- Interface: SPI
- Package / Case: 16-SSOP (0.154", 3.90mm Width)
- Series: -
- Voltage Reference: External, Internal
- Packaging: Cut Tape (CT)
- Supplier Device Package: 16-SSOP
- Voltage - Supply: 2.2V ~ 5.25V
- Part Status: Active
- Current - Supply: 500µA
- Mounting Type: Surface Mount
- Touchscreen: 4 Wire Resistive
- detail: Touchscreen Controller, 4 Wire Resistive 12 b SPI Interface 16-SSOP
