دیتاشیت LM5118MHX/NOPB

مشخصات دیتاشیت

دانلود دیتاشیت LM5118 Datasheet	LM5118 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: Step-down type;Buck-boost type
Topology: Step-down;Step-down-Boost
Datasheet: Texas Instruments LM5118MHX/NOPB
Input Voltage: 3V~75V
Duty Cycle (Max): 80%
Number of Outputs: 1
Switching Frequency: 200kHz;515kHz
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: TSSOP-20-EP
Manufacturer: Texas Instruments
Package / Case: 20-PowerTSSOP (0.173", 4.40mm Width)
Control Features: Enable, Frequency Control, Ramp, Soft Start
Output Configuration: Positive
Packaging: Cut Tape (CT)
Supplier Device Package: 20-HTSSOP
Part Status: Active
Base Part Number: LM5118
Output Type: Transistor Driver
Output Phases: 1
Synchronous Rectifier: No
Voltage - Supply (Vcc/Vdd): 3V ~ 75V
Frequency - Switching: 200kHz, 515kHz
Series: -
Mounting Type: Surface Mount
Clock Sync: Yes
Serial Interfaces: -
detail: Buck, Buck-Boost Regulator Positive Output Step-Down, Step-Up/Step-Down DC-DC Controller IC 20-HTSSOP
