دیتاشیت TPS7A3001DGNT

TPS7A30

مشخصات دیتاشیت

نام دیتاشیت TPS7A30
حجم فایل 1743.617 کیلوبایت
نوع فایل pdf
تعداد صفحات 42

دانلود دیتاشیت TPS7A30

TPS7A30 Datasheet

مشخصات

  • Voltage Dropout (Max): 0.6V @ 200mA
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
  • Control Features: Enable, Soft Start
  • Current - Output: 200mA
  • Operating Temperature: -40°C ~ 125°C
  • Output Configuration: Negative
  • Voltage - Output (Min/Fixed): -1.18V
  • Supplier Device Package: 8-MSOP-PowerPad
  • Part Status: Active
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 950µA
  • Base Part Number: TPS7A3
  • Output Type: Adjustable
  • PSRR: 72dB (120Hz)
  • Protection Features: Over Current, Over Temperature
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Max): -33V
  • Voltage - Input (Max): -35V
  • Series: -
  • Mounting Type: Surface Mount
  • Current - Quiescent (Iq): 100µA
  • Number of Regulators: 1
  • detail: Linear Voltage Regulator IC 1 Output 200mA 8-MSOP-PowerPad
