دیتاشیت LMC660CN/NOPB

LMC660

مشخصات دیتاشیت

نام دیتاشیت LMC660
حجم فایل 1359.931 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت LMC660

LMC660 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LMC660CN/NOPB
  • Rail to Rail: Push Pull;轨到轨
  • -3db Bandwidth: -
  • Output Current: 40mA
  • Number of Circuits: 4
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 0.002pA
  • Gain Bandwidth Product(GBP): 1.4MHz
  • Package: PDIP-14
  • Manufacturer: Texas Instruments
  • Base Part Number: LMC660
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Gain Bandwidth Product: 1.4MHz
  • Series: -
  • Slew Rate: 1.1V/µs
  • Current - Supply: 1.5mA
  • Voltage - Supply, Single/Dual (±): 4.75V ~ 15.5V, ±2.38V ~ 7.75V
  • Current - Input Bias: 0.002pA
  • Packaging: Tube
  • Mounting Type: Through Hole
  • Part Status: Active
  • Voltage - Input Offset: 1mV
  • Amplifier Type: General Purpose
  • Output Type: Rail-to-Rail
  • Current - Output / Channel: 40mA
  • Supplier Device Package: 14-DIP
  • detail: General Purpose Amplifier 4 Circuit Rail-to-Rail 14-DIP
