دیتاشیت ADC128S022CIMTX/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | ADC128S022 |
|---|---|
| حجم فایل | 1385.554 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت ADC128S022 |
ADC128S022 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADC128S022CIMTX/NOPB
- Interface: SPI;DSP
- resolution: 12Bit
- Supply Voltage: 2.7V~5.25V
- number of channels: 8
- sampling frequency: 200kHz
- Operating Temperature: -40°C~+105°C
- Package: TSSOP-16
- Manufacturer: Texas Instruments
- Sampling Rate (Per Second): 200k
- Number of Bits: 12
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Reference Type: Supply
- Features: -
- Part Status: Obsolete
- Series: -
- Base Part Number: ADC128
- Number of A/D Converters: 1
- Mounting Type: Surface Mount
- Configuration: MUX-S/H-ADC
- Number of Inputs: 8
- Data Interface: SPI, DSP
- Supplier Device Package: 16-TSSOP
- Voltage - Supply, Digital: 2.7V ~ 5.25V
- Architecture: SAR
- Input Type: Single Ended
- Ratio - S/H:ADC: 1:1
- Packaging: Tape & Reel (TR)
- Voltage - Supply, Analog: 2.7V ~ 5.25V
- detail: 12 Bit Analog to Digital Converter 8 Input 1 SAR 16-TSSOP
