دیتاشیت TPS54618QRTERQ1
مشخصات دیتاشیت
| نام دیتاشیت |
TPS54618-Q1
|
| حجم فایل |
1676.67
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
43
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Texas Instruments TPS54618QRTERQ1
-
Output Type:
Adjustable
-
Input Voltage:
2.95V~6V
-
Output Voltage:
0.799V~4.5V
-
Number of Outputs:
1
-
Switching Frequency:
2MHz
-
Output Current (Max):
6A
-
Operating Temperature:
-40°C~+125°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
QFN-16-EP(3x3)
-
Manufacturer:
Texas Instruments
-
Frequency - Switching:
200kHz ~ 2MHz
-
Package / Case:
16-WFQFN Exposed Pad
-
Supplier Device Package:
16-WQFN (3x3)
-
Voltage - Output (Min/Fixed):
0.799V
-
Current - Output:
6A
-
Output Configuration:
Positive
-
Packaging:
Digi-Reel®
-
Part Status:
Active
-
Voltage - Output (Max):
4.5V
-
Series:
Automotive, AEC-Q100, SWIFT™
-
Mounting Type:
Surface Mount
-
Voltage - Input (Max):
6V
-
Base Part Number:
TPS546
-
Voltage - Input (Min):
2.95V
-
Synchronous Rectifier:
Yes
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.799V 1 Output 6A 16-WFQFN Exposed Pad
