TMUX6119DCNR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TMUX6119DCNR	دانلود دیتاشیت

TMUX6119 29 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TMUX6119DCNR
Turn-on time: 86ns
Turn-off time: 64ns
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 165Ω
Package: SOT-23-8
Manufacturer: Texas Instruments
Base Part Number: TMUX61
Charge Injection: -0.19pC
Channel Capacitance (CS(off), CD(off)): 1.9pF, 4.3pF
Package / Case: SOT-23-8
Series: -
Supplier Device Package: SOT-23-8
Switch Time (Ton, Toff) (Max): 86ns, 64ns
Part Status: Active
Operating Temperature: -40°C ~ 125°C (TA)
Crosstalk: -93dB @ 1MHz
Packaging: Cut Tape (CT)
Mounting Type: Surface Mount
Channel-to-Channel Matching (ΔRon): 2.4mOhm
Number of Circuits: 1
-3db Bandwidth: 700MHz
Multiplexer/Demultiplexer Circuit: 2:1
Current - Leakage (IS(off)) (Max): 20pA
Voltage - Supply, Dual (V±): ±5V ~ 16.5V
detail: 1 Circuit IC Switch 2:1 165Ohm SOT-23-8
