دیتاشیت LM2675MX-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2675 |
|---|---|
| حجم فایل | 1461.019 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 35 |
دانلود دیتاشیت LM2675 |
LM2675 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments LM2675MX-ADJ/NOPB
- Output Type: Adjustable
- Input Voltage: 6.5V~40V
- Output Voltage: 1.21V~37V
- Number of Outputs: 1
- Switching Frequency: 260kHz
- Output Current (Max): 1A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: SOP-8
- Manufacturer: Texas Instruments
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Output Configuration: Positive
- Base Part Number: LM2675
- Packaging: Cut Tape (CT)
- Frequency - Switching: 260kHz
- Supplier Device Package: 8-SOIC
- Part Status: Obsolete
- Current - Output: 1A
- Series: SIMPLE SWITCHER®
- Voltage - Input (Max): 40V
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 1.21V
- Voltage - Input (Min): 6.5V
- Mounting Type: Surface Mount
- Voltage - Output (Max): 37V
- detail: Buck Switching Regulator IC Positive Adjustable 1.21V 1 Output 1A 8-SOIC (0.154", 3.90mm Width)
