ISO7131CCDBQ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ISO7131CCDBQ
|
|
حجم فایل
|
95.457
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
34
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Digital Isolators
-
Data Rate:
50Mbps
-
Datasheet:
Texas Instruments ISO7140CCDBQR
-
Applications:
General-purpose
-
Supply Voltage:
2.7V~5.5V
-
Forward Channel:
4
-
Reverse channel:
0
-
Number of Channels:
4
-
Isolation Technology:
电容隔离
-
Operating Temperature:
-40°C~+125°C
-
Voltage Isolation or Not:
带电压隔离
-
Package:
SSOP-16-150mil-0.635mm
-
Manufacturer:
Texas Instruments
-
Inputs - Side 1/Side 2:
4/0
-
Package / Case:
16-SSOP (0.154", 3.90mm Width)
-
Rise / Fall Time (Typ):
2ns, 2ns
-
Type:
General Purpose
-
Packaging:
Cut Tape (CT)
-
Supplier Device Package:
16-SSOP
-
Part Status:
Active
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Base Part Number:
ISO7140
-
Pulse Width Distortion (Max):
3ns
-
Isolated Power:
No
-
Channel Type:
Unidirectional
-
Voltage - Supply:
2.7V ~ 5.5V
-
Series:
-
-
Propagation Delay tpLH / tpHL (Max):
35ns, 35ns
-
Mounting Type:
Surface Mount
-
Voltage - Isolation:
2500Vrms
-
Technology:
Capacitive Coupling
-
detail:
General Purpose Digital Isolator 2500Vrms 4 Channel 50Mbps 25kV/µs CMTI 16-SSOP (0.154", 3.90mm Width)
