دیتاشیت ESDZL5-1F4
مشخصات دیتاشیت
نام دیتاشیت |
ESDZL5-1F4
|
حجم فایل |
438.321
کیلوبایت
|
نوع فایل |
pdf
|
تعداد صفحات |
9
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
ESDZ
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Unidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
5.5V (Max)
-
Voltage - Breakdown (Min):
-
-
Voltage - Clamping (Max) @ Ipp:
10V
-
Current - Peak Pulse (10/1000µs):
7A (8/20µs)
-
Power - Peak Pulse:
60W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
7.5pF @ 1MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
0201 (0603 Metric)
-
Supplier Device Package:
0201
-
Base Part Number:
ESDZL5
-
detail:
10V Clamp 7A (8/20µs) Ipp Tvs Diode Surface Mount 0201
