DRV8711DCPR دیتاشیت

DRV8711DCPR

مشخصات دیتاشیت

نام دیتاشیت DRV8711DCPR
حجم فایل 91.452 کیلوبایت
نوع فایل pdf
تعداد صفحات 38

دانلود دیتاشیت DRV8711DCPR

دانلود دیتاشیت

سایر مستندات

DRV8711 52 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Texas Instruments DRV8711DCPR
  • Package: HTSSOP-38-EP-4.4mm
  • Manufacturer: Texas Instruments
  • Package / Case: 38-TFSOP (0.173", 4.40mm Width) Exposed Pad
  • Part Status: Active
  • Base Part Number: DRV8711
  • Current - Output: -
  • Series: -
  • Voltage - Supply: 8V ~ 52V
  • Technology: -
  • Mounting Type: Surface Mount
  • Voltage - Load: -
  • Motor Type - AC, DC: Brushed DC
  • Interface: SPI, Step/Direction
  • Motor Type - Stepper: Bipolar
  • Packaging: Cut Tape (CT)
  • Function: Controller - Commutation, Direction Management
  • Output Configuration: Pre-Driver - Half Bridge (4)
  • Supplier Device Package: 38-HTSSOP
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Step Resolution: 1 ~ 1/256
  • Applications: General Purpose
  • detail: Bipolar Motor Driver SPI, Step/Direction 38-HTSSOP
