دیتاشیت ESDCAN04-2BLY
مشخصات دیتاشیت
| نام دیتاشیت |
ESDCANxx-2BLY
|
| حجم فایل |
885.49
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
14
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
STMicroelectronics ESDCAN04-2BLY
-
Number of Lines:
2
-
Clamping Voltage@Ipp:
43V
-
Operating Temperature:
-40°C~+150°C@(Tj)
-
Breakdown Voltage (VBR):
27.5V
-
Peak Pulse Power(Ppp)@8/20us:
230W
-
Junction Capacitance(Cj)@1MHz:
17pF@1MHz
-
Peak Pulse Current(Ipp)@8/20us:
3.7A@(8/20us)
-
Reverse Stand-Off Voltage (Vrwm):
25.5V
-
Package:
SOT-23
-
Manufacturer:
STMicroelectronics
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Bidirectional Channels:
2
-
Voltage - Reverse Standoff (Typ):
25.5V
-
Voltage - Breakdown (Min):
27.5V
-
Voltage - Clamping (Max) @ Ipp:
43V
-
Current - Peak Pulse (10/1000µs):
3.7A (8/20µs)
-
Power - Peak Pulse:
230W
-
Power Line Protection:
No
-
Applications:
Automotive, CAN
-
Capacitance @ Frequency:
17pF @ 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
detail:
43V Clamp 3.7A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3
