دیتاشیت ESDAXLC6-1BT2
مشخصات دیتاشیت
| نام دیتاشیت |
ESDAXLC6-1BT2
|
| حجم فایل |
224.568
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Type:
-
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Polarity:
Bi-Directional
-
Datasheet:
STMicroelectronics ESDAXLC6-1BT2
-
Machine Model:
-
-
Number of Lines:
-
-
Clamping Voltage@Ipp:
41V
-
Operating Temperature:
-40°C~+150°C@(Tj)
-
Breakdown Voltage (VBR):
6V
-
Reverse Leakage Current:
-
-
Peak Pulse Power(Ppp)@8/20us:
40W
-
Junction Capacitance(Cj)@1MHz:
0.4pF@200MHz~3GHz
-
Peak Pulse Current(Ipp)@8/20us:
1A
-
Reverse Stand-Off Voltage (Vrwm):
3V
-
Package:
SOD-882
-
Manufacturer:
STMicroelectronics
-
Series:
ESDA
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Bidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
3V
-
Voltage - Breakdown (Min):
6V
-
Voltage - Clamping (Max) @ Ipp:
17V
-
Current - Peak Pulse (10/1000µs):
1A (8/20µs)
-
Power - Peak Pulse:
40W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
0.4pF @ 200MHz ~ 3GHz
-
Mounting Type:
Surface Mount
-
Package / Case:
SOD-882
-
Supplier Device Package:
SOD-882T
-
Base Part Number:
ESDAXLC6
-
detail:
17V Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount SOD-882T
