دیتاشیت LM73606RNPT
مشخصات دیتاشیت
| نام دیتاشیت | LM73606RNPT |
|---|---|
| حجم فایل | 96.42 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 54 |
LM73606RNPT |
دانلود دیتاشیت |
|---|
سایر مستندات
LM73605, LM73606 Datasheet 53 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments LM73606RNPT
- Output Type: Adjustable
- Input Voltage: 3.5V~36V
- Output Voltage: 1V~34.2V
- Number of Outputs: 1
- Switching Frequency: 2.2MHz
- Output Current (Max): 6A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: QFN-30-EP(4x6)
- Manufacturer: Texas Instruments
- Part Status: Active
- Current - Output: 6A
- Package / Case: 30-WFQFN Exposed Pad
- Base Part Number: LM7360
- Synchronous Rectifier: Yes
- Series: -
- Voltage - Input (Min): 3.5V
- Voltage - Output (Min/Fixed): 1V
- Voltage - Output (Max): 34.2V
- Mounting Type: Surface Mount, Wettable Flank
- Frequency - Switching: 350kHz ~ 2.2MHz
- Packaging: Cut Tape (CT)
- Output Configuration: Positive
- Supplier Device Package: 30-WQFN (6x4)
- Voltage - Input (Max): 36V
- detail: Buck Switching Regulator IC Positive Adjustable 1V 1 Output 6A 30-WFQFN Exposed Pad
