دیتاشیت STPS1L40ZFY

STPS1L40ZFY

مشخصات دیتاشیت

نام دیتاشیت STPS1L40ZFY
حجم فایل 47.018 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

STPS1L40ZFY

دانلود دیتاشیت

سایر مستندات

Products & Solutions Solar Energy Brochure 28 pages

STPS1L40 Datasheet 16 pages

Diodes and Rectifiers Selection Guide 28 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: STMicroelectronics STPS1L40ZFY
  • Reverse Voltage (Vr): 40V
  • Forward Voltage (Vf@If): 500mV@1A
  • Reverse Leakage Current (Ir): 35uA@40V
  • Average Rectified Current (Io): 1A
  • Package: SOD-123FL
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 40V
  • Current - Average Rectified (Io): 1A
  • Voltage - Forward (Vf) (Max) @ If: 500mV @ 1A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 35µA @ 40V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: SOD-123F
  • Supplier Device Package: SOD-123F
  • Operating Temperature - Junction: -40°C ~ 175°C
  • Base Part Number: STPS1
  • detail: Diode Schottky 40V 1A Surface Mount SOD-123F
