دیتاشیت LM317LD13TR
مشخصات دیتاشیت
| نام دیتاشیت | LMx17L Datasheet |
|---|---|
| حجم فایل | 678.715 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 23 |
دانلود دیتاشیت LMx17L Datasheet |
LMx17L Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: STMicroelectronics LM317LD13TR
- Output Type: Adjustable
- Output Current: 100mA
- Output Voltage: 1.2V~37V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 40V
- Operating Temperature: 0°C~+125°C
- Quiescent Current (Ground Current): 5mA
- Power Supply Rejection Ratio (PSRR): 80dB@(120Hz)
- Package: SOP-8
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 1.2V
- Voltage - Output (Max): 37V
- Voltage Dropout (Max): -
- Current - Output: 100mA
- PSRR: 80dB ~ 65dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SO
- Base Part Number: LM317
- detail: Linear Voltage Regulator IC 1 Output 100mA 8-SO
