LM2903YDT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LM2903YDT
|
|
حجم فایل
|
65.131
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
20
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
STMicroelectronics LM2903YDT
-
Output Type:
开集;轨到轨
-
Supply Current:
2.5mA
-
Supply Voltage:
2V~36V;1V~18V
-
Number of Elements:
2
-
Operating Temperature:
-40°C~+125°C
-
Input Bias Current (Ib):
0.25uA
-
Input Offset Voltage (Vos):
7mV
-
Input Hysteresis Voltage (Vhys):
-
-
Common Mode Rejection Ratio (CMRR):
-
-
Package:
SOP-8
-
Manufacturer:
STMicroelectronics
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
General Purpose
-
Voltage - Supply, Single/Dual (±):
2V ~ 36V, ±1V ~ 18V
-
Voltage - Input Offset (Max):
7mV @ 5V
-
Current - Input Bias (Max):
0.25µA @ 5V
-
Current - Output (Typ):
16mA @ 5V
-
Current - Quiescent (Max):
2.5mA
-
CMRR, PSRR (Typ):
-
-
Propagation Delay (Max):
-
-
Hysteresis:
-
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
8-SO
-
Base Part Number:
LM2903
-
detail:
Comparator General Purpose CMOS, DTL, ECL, MOS, Open-Collector, TTL 8-SO
