دیتاشیت ESDALC6V1-5M6
مشخصات دیتاشیت
| نام دیتاشیت | ESDALC6V1(-5)M6 |
|---|---|
| حجم فایل | 309.415 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت ESDALC6V1(-5)M6 |
ESDALC6V1(-5)M6 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: STMicroelectronics ESDALC6V1-5M6
- Number of Lines: 5
- Clamping Voltage@Ipp: 6.1V
- Operating Temperature: -40°C~+125°C@(Tj)
- Breakdown Voltage (VBR): 6.1V
- Peak Pulse Power(Ppp)@8/20us: 30W
- Junction Capacitance(Cj)@1MHz: 12pF@1MHz
- Peak Pulse Current(Ipp)@8/20us: -
- Reverse Stand-Off Voltage (Vrwm): 3V
- Package: UQFN-6(1.45x1)
- Manufacturer: STMicroelectronics
- Series: ESDA, TRANSIL™
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 5
- Voltage - Reverse Standoff (Typ): 3V
- Voltage - Breakdown (Min): 6.1V
- Voltage - Clamping (Max) @ Ipp: -
- Current - Peak Pulse (10/1000µs): -
- Power - Peak Pulse: 30W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 12pF @ 1MHz
- Mounting Type: Surface Mount
- Package / Case: 6-UFDFN
- Supplier Device Package: 6-µQFN (1.45x1.0)
- Base Part Number: ESDALC6V1
- detail: Clamp Ipp Tvs Diode Surface Mount 6-µQFN (1.45x1.0)
