دیتاشیت MC33078DT

MC33078

مشخصات دیتاشیت

نام دیتاشیت MC33078
حجم فایل 385.891 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت MC33078

MC33078 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: STMicroelectronics MC33078DT
  • -3db Bandwidth: -
  • Output Current: 37mA
  • Operating Temperature: -40°C~+105°C
  • Current - Input Bias(Ib): 250nA
  • Gain Bandwidth Product(GBP): 15MHz
  • Package: SOIC-8
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Amplifier Type: General Purpose
  • Number of Circuits: 2
  • Output Type: -
  • Slew Rate: 7V/µs
  • Gain Bandwidth Product: 15MHz
  • Current - Input Bias: 250nA
  • Voltage - Input Offset: 150µV
  • Current - Supply: 4mA
  • Current - Output / Channel: 37mA
  • Voltage - Supply, Single/Dual (±): 5V ~ 30V, ±2.5V ~ 15V
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SO
  • Base Part Number: MC3307
  • detail: General Purpose Amplifier 2 Circuit 8-SO
