دیتاشیت STPS4S200S

STPS4S200

مشخصات دیتاشیت

نام دیتاشیت STPS4S200
حجم فایل 316.748 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت STPS4S200

STPS4S200 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: STMicroelectronics STPS4S200S
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 200V
  • Forward Voltage (Vf@If): 870mV@4A
  • Reverse Leakage Current (Ir): 5uA@200V
  • Average Rectified Current (Io): 4A
  • Package: SMC(DO-214AB)
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io): 4A
  • Voltage - Forward (Vf) (Max) @ If: 870mV @ 4A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 5µA @ 200V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: DO-214AB, SMC
  • Supplier Device Package: SMC
  • Operating Temperature - Junction: 175°C (Max)
  • Base Part Number: STPS4
  • detail: Diode Schottky 200V 4A Surface Mount SMC
