دیتاشیت REF3112/20/25/30/33/40

REF3112/20/25/30/33/40

مشخصات دیتاشیت

نام دیتاشیت REF3112/20/25/30/33/40
حجم فایل 1333.836 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

REF3112/20/25/30/33/40

دانلود دیتاشیت

سایر مستندات

REF3125AIDBZT 27 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Texas Instruments REF3112AIDBZT
  • Tolerance: ±0.2%
  • Output Type: Fixed
  • Input Voltage: 1.8V~5.5V
  • Output Current: 10mA
  • Output Voltage: 1.25V
  • Reference Type: series connection
  • Supply Current: 135uA
  • Noise - 10Hz to 10kHz: 24uVrms
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Noise - 1/10Hz to 10Hz: 17uVp-p
  • Temperature Coefficient: 20ppm/°C
  • Package: SOT-23-3
  • Manufacturer: Texas Instruments
  • Part Status: Active
  • Current - Supply: 135µA
  • Current - Output: 10mA
  • Series: -
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Voltage - Output (Min/Fixed): 1.25V
  • Base Part Number: REF311
  • Mounting Type: Surface Mount
  • Noise - 0.1Hz to 10Hz: 17µVp-p
  • Voltage - Input: 1.8V ~ 5.5V
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: SOT-23-3
  • detail: Series Voltage Reference IC ±0.2% SOT-23-3
