- دیتاشیت LP3966ESX-ADJ/NOPB
LP3966ESX-ADJ/NOPB دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LP3966ESX-ADJ/NOPB |
|---|---|
| حجم فایل | 103.987 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت LP3966ESX-ADJ/NOPB |
دانلود دیتاشیت |
|---|
سایر مستندات
LP3963,66 Datasheet 25 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP3966ESX-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 3A
- Output Voltage: 1.216V~5.1V
- Dropout Voltage: 1.2V@(3A)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 7V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 9mA
- Power Supply Rejection Ratio (PSRR): -
- Package: TO-263-5
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 1.2V @ 3A
- Current - Supply (Max): 15mA
- Current - Output: 3A
- Current - Quiescent (Iq): 9mA
- Voltage - Input (Max): 7V
- Base Part Number: LP3966
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Voltage - Output (Max): 5.1V
- Output Configuration: Positive
- Series: -
- Supplier Device Package: DDPAK/TO-263-5
- PSRR: -
- Part Status: Discontinued at Digi-Key
- Mounting Type: Surface Mount
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Output (Min/Fixed): 1.216V
- Number of Regulators: 1
- Packaging: Cut Tape (CT)
- detail: Linear Voltage Regulator IC 1 Output 3A DDPAK/TO-263-5
