دیتاشیت TPS74401RGWTG4
مشخصات دیتاشیت
| نام دیتاشیت |
TPS74401
|
| حجم فایل |
1478.483
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
42
|
مشخصات
-
Part Status:
Active
-
Current - Output:
3A
-
Series:
-
-
Package / Case:
20-VQFN Exposed Pad
-
Voltage - Output (Min/Fixed):
0.8V
-
Control Features:
Enable, Power Good, Soft Start
-
Number of Regulators:
1
-
Mounting Type:
Surface Mount
-
Voltage - Output (Max):
3.6V
-
Base Part Number:
TPS744
-
Protection Features:
Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
-
PSRR:
73dB ~ 50dB (1kHz ~ 800kHz)
-
Voltage Dropout (Max):
0.24V @ 3A
-
Packaging:
Cut Tape (CT)
-
Manufacturer:
Texas Instruments
-
Output Type:
Adjustable
-
Output Configuration:
Positive
-
Supplier Device Package:
20-VQFN (5x5)
-
Operating Temperature:
-40°C ~ 125°C
-
Voltage - Input (Max):
5.5V
-
detail:
Linear Voltage Regulator IC 1 Output 3A 20-VQFN (5x5)
