دیتاشیت MSP430F449IPZR

مشخصات دیتاشیت

دانلود دیتاشیت MSP430x43x1/43x/44x1/44x Datasheet	MSP430x43x1/43x/44x1/44x Datasheet Datasheet

RoHS: true
CPU Core: MSP430
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
Datasheet: Texas Instruments MSP430F449IPZR
LCD Module: Yes
CPU Maximum Speed: 8MHz
GPIO Ports Number: 48
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Program Storage Size: 60KB
Operating Voltage Range: 1.8V~3.6V
Operating Temperature Range: -40°C~+85°C
Package: LQFP-100(14x14)
Manufacturer: Texas Instruments
Mounting Type: Surface Mount
RAM Size: 2K x 8
Connectivity: SPI, UART/USART
Packaging: Cut Tape (CT)
Data Converters: A/D 8x12b
Number of I/O: 48
Core Size: 16-Bit
Core Processor: MSP430
Supplier Device Package: 100-LQFP (14x14)
Operating Temperature: -40°C ~ 85°C (TA)
Part Status: Active
EEPROM Size: -
Package / Case: 100-LQFP
Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
Program Memory Size: 60KB (60K x 8 + 256B)
Base Part Number: 430F449
Speed: 8MHz
Series: MSP430x4xx
Oscillator Type: Internal
Program Memory Type: FLASH
Peripherals: Brown-out Detect/Reset, LCD, POR, PWM, WDT
detail: MSP430 MSP430x4xx Microcontroller IC 16-Bit 8MHz 60KB (60K x 8 + 256B) FLASH 100-LQFP (14x14)
