TYN640RG دیتاشیت

TYN640RG

مشخصات دیتاشیت

نام دیتاشیت TYN640RG
حجم فایل 46.17 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

مشاهده دیتاشیت TYN640RG

دانلود دیتاشیت

سایر مستندات

TYNx40 Series 8 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: One-way thyristor
  • Datasheet: STMicroelectronics TYN640RG
  • Holding Current (Ih): 75mA
  • Operating Temperature: -40°C~+125°C
  • Gate Trigger Current(Igt): 35mA
  • Gate Trigger Voltage (Vgt): 1.3V
  • RMS On-State Current(It (rms)): 40A
  • Peak Forward On?State Voltage (Vtm): 1.6V
  • Peak Repetitive Off?State Voltage (Vdrm): 600V
  • Package: TO-220AB-3
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Voltage - Off State: 600V
  • Voltage - Gate Trigger (Vgt) (Max): 1.3V
  • Current - Gate Trigger (Igt) (Max): 35mA
  • Voltage - On State (Vtm) (Max): 1.6V
  • Current - On State (It (AV)) (Max): 25A
  • Current - On State (It (RMS)) (Max): 40A
  • Current - Hold (Ih) (Max): 75mA
  • Current - Off State (Max): 5µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 460A, 480A
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: TYN640
  • detail: SCR 600V 40A Standard Recovery Through Hole TO-220AB
